Moxin Controller Kit (Surron lbx)

Moxin S801100 Controller – Sur-Ron Light Bee X

High-performance sine wave controller built for the Sur-Ron Light Bee X. 61.6kW peak power, 1100A phase current, and 10M waterproofing — built to handle serious upgrades.

Specifications

• Model: S801100
• Rated Voltage: 48V–80V
• Input Voltage: 40V–94V
• Rated Power: 16kW
• Peak Power: 61.6kW (10s)
• Peak Phase Current: 1100A
• Continuous Bus Current: 500A
• Power Tubes: 30x TOLL SC (±1500A, 5µs response)
• Max RPM: 200,000 (1 pair) · 50,000 (4 pairs) · 12,500 (16 pairs)
• Control Response: 1000x/sec, 1ms delay
• Efficiency: 99% typical · 96%+ at peak
• Waterproof: 10M water resistant + high pressure water gun protection
• Operating Temp: -40°C to 75°C
• Dimensions: 281mm x 98mm x 63mm
• Weight: 2.8kg

Regen Methods Throttle recovery · Brake power-off recovery · Linear electronic braking

Key Features

• One-click motor self-learning & parameter identification
• Tilt-head auxiliary function for wheelies
• High pressure waterproof rated
• Direct fit for Sur-Ron Light Bee X

Fitment: Sur-Ron Light Bee X
